Namespace: tilegrid

olx.tilegrid


import tilegrid from 'olx/tilegrid';

Type Definitions

olx.tilegrid.TileGridOptions{Object}

Properties:
Name Type Argument Description
extent ol.Extent | undefined <optional>

Extent for the tile grid. No tiles outside this extent will be requested by ol.source.Tile sources. When no origin or origins are configured, the origin will be set to the top-left corner of the extent.

minZoom number | undefined <optional>

Minimum zoom. Default is 0.

origin ol.Coordinate | undefined <optional>

The tile grid origin, i.e. where the x and y axes meet ([z, 0, 0]). Tile coordinates increase left to right and upwards. If not specified, extent or origins must be provided.

origins Array.<ol.Coordinate> | undefined <optional>

Tile grid origins, i.e. where the x and y axes meet ([z, 0, 0]), for each zoom level. If given, the array length should match the length of the resolutions array, i.e. each resolution can have a different origin. Tile coordinates increase left to right and upwards. If not specified, extent or origin must be provided.

resolutions Array.<number>

Resolutions. The array index of each resolution needs to match the zoom level. This means that even if a minZoom is configured, the resolutions array will have a length of maxZoom + 1. Required.

tileSize number | ol.Size | undefined <optional>

Tile size. Default is [256, 256].

tileSizes Array.<(number|ol.Size)> | undefined <optional>

Tile sizes. If given, the array length should match the length of the resolutions array, i.e. each resolution can have a different tile size.

olx.tilegrid.WMTSOptions{Object}

Properties:
Name Type Argument Description
extent ol.Extent | undefined <optional>

Extent for the tile grid. No tiles outside this extent will be requested by ol.source.Tile sources. When no origin or origins are configured, the origin will be set to the top-left corner of the extent.

origin ol.Coordinate | undefined <optional>

The tile grid origin, i.e. where the x and y axes meet ([z, 0, 0]). Tile coordinates increase left to right and upwards. If not specified, extent or origins must be provided.

origins Array.<ol.Coordinate> | undefined <optional>

Tile grid origins, i.e. where the x and y axes meet ([z, 0, 0]), for each zoom level. If given, the array length should match the length of the resolutions array, i.e. each resolution can have a different origin. Tile coordinates increase left to right and upwards. If not specified, extent or origin must be provided.

resolutions Array.<number>

Resolutions. The array index of each resolution needs to match the zoom level. This means that even if a minZoom is configured, the resolutions array will have a length of maxZoom + 1 Required.

matrixIds Array.<string>

matrix IDs. The length of this array needs to match the length of the resolutions array. Required.

sizes Array.<ol.Size> | undefined <optional>

Number of tile rows and columns of the grid for each zoom level. The values here are the TileMatrixWidth and TileMatrixHeight advertised in the GetCapabilities response of the WMTS, and define the grid's extent together with the origin. An extent can be configured in addition, and will further limit the extent for which tile requests are made by sources. Note that when the top-left corner of the extent is used as origin or origins, then the y value must be negative because OpenLayers tile coordinates increase upwards.

tileSize number | ol.Size | undefined <optional>

Tile size.

tileSizes Array.<(number|ol.Size)> | undefined <optional>

Tile sizes. The length of this array needs to match the length of the resolutions array.

widths Array.<number> | undefined <optional>

Number of tile columns that cover the grid's extent for each zoom level. Only required when used with a source that has wrapX set to true, and only when the grid's origin differs from the one of the projection's extent. The array length has to match the length of the resolutions array, i.e. each resolution will have a matching entry here.

olx.tilegrid.XYZOptions{Object}

Properties:
Name Type Argument Description
extent ol.Extent | undefined <optional>

Extent for the tile grid. The origin for an XYZ tile grid is the top-left corner of the extent. The zero level of the grid is defined by the resolution at which one tile fits in the provided extent. If not provided, the extent of the EPSG:3857 projection is used.

maxZoom number | undefined <optional>

Maximum zoom. The default is ol.DEFAULT_MAX_ZOOM. This determines the number of levels in the grid set. For example, a maxZoom of 21 means there are 22 levels in the grid set.

minZoom number | undefined <optional>

Minimum zoom. Default is 0.

tileSize number | ol.Size | undefined <optional>

Tile size in pixels. Default is [256, 256].
